Pump-Over Fermenter
Pump-Over Fermenter
The pump-over fermenter is designed to simplify remontage and demontage during red wine fermentation. The HELI rotating sprinkler evenly distributes wine over the pomace cap, while a built-in sieve separates solids from liquid for efficient pump-over circulation. Optional automation can further streamline the process.
Additional systems improve mixing and discharge. Pneumatic agitation gently mixes the must with bubbles from the bottom of the tank, while rotating paddles help remove pomace after fermentation.
A touchscreen control panel allows precise control of temperature and pump cycles, ensuring consistent fermentation conditions.
The large dimple cooling jacket provides reliable temperature control, efficiently chilling the tank even when it is not filled to full capacity. The fermenter is built from high-quality stainless steel for durability and long-term winery use.
Tank Options
- Wheels
- Stand for Forklift Transport
- PU Foam Insulation
- Green Line Stainless Steel
- Stackable
Basic Equipment
• HELI Rotating Sprinkler
• Pipe – DN32 DIN11851 (with fitting)
• Manhole Cover – Round Ø400 mm
• Manway Door – Rectangular (type Z1500)
• Legs – Standard (Closed)
• Cooling Jacket (1 m2/1000 L)
• Thermometer (analog)
• Thermowell (with PG9 fitting)
• Sample Tap (DN15)
• Partial Discharge – Ball valve (DN32 DIN)
• Total Discharge – Ball valve (DN65 DIN)
• Vent Valve – DN50 (PVC)
• Mesh Screen
• Level Indicator – Ø16 mm acrylic tube (scaled, open)
• Type Plate – With note card
• Ladder Rack – Coat height 1500 mm onwards
• Welding – Brushed finish
Additional Equipment
• Automatic Pomace Discharge
• Automatic Pulsation Devices
• Control Panel (touchscreen) – Temperature and Pump Control
• Pump (for pumping over)
• Manway Door – Custom sizes
• Additional oval door (on hinge)
• Legs – Adjustable height and tilt
• Heating Jacket
• Cooling Jacket (>1 m2/1000 L)
• Bottom-mounted electrical heater
• Digital thermoregulator (with temperature control)
• Ball or butterfly (Clamp, Garolla, WG, Macon, GAS, etc.)
• Electromagnetic or electromotor valves
• Stainless steel caps (on all valves and fittings)
• Inclined stirrer fitting
• Inert gas fitting
• Level Indicator – Ø24 mm acrylic tube (scaled, closed)
• Decanter
• Welding – Brushed and polished (Ra<0.8 µm)
• Other additional equipment available per customer request
3D
| Type | Volume | Ø (mm) | H (mm) | H1 (mm) | H2 (mm) | D (mm) | Bottom/top |
|---|---|---|---|---|---|---|---|
| VIK2300A14 | 2.300 lit | 1.402 | 2.361 | 1.500 | 500 | 2.342 | B4/T1 |
| VIK3100A14 | 3.100 lit | 2.861 | 2.000 | 500 | 2.815 | B4/T1 | |
| VIK3800A14 | 3.800 lit | 3.361 | 2.500 | 500 | 3.313 | B4/T1 | |
| VIK4000A16 | 4.000 lit | 1.593 | 2.874 | 2.000 | 500 | 2.856 | B4/T1 |
| VIK5000A16 | 5.000 lit | 3.374 | 2.500 | 500 | 3.326 | B4/T1 | |
| VIK5900A16 | 5.900 lit | 3.874 | 3.000 | 500 | 3.825 | B4/T1 | |
| VIK4900A18 | 4.900 lit | 1.752 | 2.886 | 2.000 | 500 | 2.913 | B4/T1 |
| VIK6100A18 | 6.100 lit | 3.386 | 2.500 | 500 | 3.363 | B4/T1 | |
| VIK7300A18 | 7.300 lit | 3.886 | 3.000 | 500 | 3.836 | B4/T1 | |
| VIK8500A21 | 8.500 lit | 2.071 | 3.446 | 2.500 | 500 | 3.455 | B4/T2 |
| VIK10200A21 | 10.200 lit | 3.946 | 3.000 | 500 | 3.904 | B4/T2 | |
| VIK13500A21 | 13.500 lit | 4.946 | 4.000 | 500 | 4.894 | B4/T2 | |
| VIK11700A22 | 11.700 lit | 2.230 | 3.964 | 3.000 | 500 | 3.958 | B4/T2 |
| VIK12700A22 | 12.700 lit | 4.214 | 3.250 | 500 | 4.184 | B4/T2 | |
| VIK13700A22 | 13.700 lit | 4.464 | 3.500 | 500 | 4.412 | B4/T2 | |
| VIK15700A22 | 15.700 lit | 4.964 | 4.000 | 500 | 4.910 | B4/T2 | |
| VIK13450A24 | 13.450 lit | 2.389 | 3.981 | 3.000 | 500 | 4.014 | B4/T2 |
| VIK15800A24 | 15.800 lit | 4.481 | 3.500 | 500 | 4.463 | B4/T2 | |
| VIK18100A24 | 18.100 lit | 4.981 | 4.000 | 500 | 4.926 | B4/T2 | |
| VIK14800A25 | 14.800 lit | 2.501 | 4.026 | 3.000 | 500 | 4.199 | B4/T2 |
| VIK17300A25 | 17.300 lit | 4.526 | 3.500 | 500 | 4.634 | B4/T2 | |
| VIK19700A25 | 19.700 lit | 5.026 | 4.000 | 500 | 5.080 | B4/T2 | |
| VIK24600A25 | 24.600 lit | 6.026 | 5.000 | 500 | 5.998 | B4/T2 | |
| VIK17300A27 | 17.300 lit | 2.708 | 4.050 | 3.000 | 500 | 4.276 | B4/T2 |
| VIK20300A27 | 20.300 lit | 4.550 | 3.500 | 500 | 4.703 | B4/T2 | |
| VIK23400A27 | 23.400 lit | 5.050 | 4.000 | 500 | 5.144 | B4/T2 | |
| VIK29100A27 | 29.100 lit | 6.050 | 5.000 | 500 | 6.053 | B4/T2 |
Other tank sizes available per client request
Can't Find the Ideal Tank?
Talk to one of our engineers and describe your requirements. We will design a unique solution perfect for your processing needs.
Frequently Asked Questions
What is a pump-over fermenter used for in winemaking?
A pump-over fermenter is a stainless steel red wine fermentation tank designed to simplify remontage (pump-over) and demontage (pomace removal). It allows wineries to efficiently circulate wine over the pomace cap during fermentation while maintaining precise temperature control.
How does the HELI rotating sprinkler improve pump-over fermentation?
The HELI rotating sprinkler is mounted on top of the fermenter and evenly distributes wine over the pomace cap during pump-over. This ensures consistent extraction of color, tannins, and aromas, improving fermentation efficiency and overall wine quality.
What systems help mix the must during fermentation?
The pump-over fermenter can include pneumatic impulse mixing, where devices at the bottom of the tank release short bursts of air. The rising bubbles gently mix the must, improving extraction while avoiding excessive mechanical agitation.
How is pomace removed from the fermentation tank?
After fermentation, rotating blades at the bottom of the tank help push leftover pomace toward rectangular discharge doors, making pomace removal faster and more efficient. This automated discharge system simplifies cellar operations during red wine production.
How does the pump-over fermenter control fermentation temperature?
The tank features a dimple cooling jacket that circulates a cooling or heating medium such as glycol. Combined with a programmable touchscreen control panel, winemakers can regulate temperature and pump cycles to maintain optimal fermentation conditions.
